source:Industry News release time:2021-11-15 Article author:sznbone Popular:pcb
The basic design process of the circuit board can be divided into the following steps:
1. The design principle of the circuit schematic diagram.
(1) The principle editor is mainly used to draw the principle diagram and generate the network, and display the report of the circuit principle and the link relationship of each element.
(2) Design printed circuit boards and generate circuit board reports, such as generating various reports, such as network status reports, circuit board information reports, and so on.
2. The design steps of the circuit schematic diagram:
(1) Set the size and layout of the schematic diagram of the circuit, and move the components taken from the component library to the working plane.
(2) Connect the components according to the design requirements, and adjust the components after wiring.
(3) Electromagnetic design of structural cables
(4) Electromagnetic design of printed circuit board
(5) Electromagnetic design of main equipment
(6) Printed circuit board manufacturing and function debugging
There are many steps in circuit board design. If the defects and flaws found in the design are found, the success will fall short.
